Meet The ATV X3
Light. Tough. Rugged.
The Advanced Offroad Trailer ATV X3 is engineered for maximum strength with minimum weight. Designed to follow your ATV anywhere it can go. This ATV performance trailer delivers unmatched offroad performance with class-leading features and a lifetime warranty
The most advanced ATV Trailer on the market
In contrast to typical ATV trailers that rely on rigid axles or limited articulation, the ATV X3 is equipped with independent 3500 lb-rated swing arms, polyurethane bushings, and a built-in anti-sway bar — offering precise handling, reduced frame stress, and virtually silent towing. Additionally, over 100 integrated tie-down points, full floating ground with rubber-coated electrical wiring, and integrated air and wiring channels show just how much attention has gone into every detail. This isn’t just an ATV trailer — it’s a professional-grade tool designed for serious adventure. Whereas most off-road trailers are adaptations of on-road models, the ATV X3 is engineered from the ground up for rugged, high-angle terrain and heavy-duty hauling, making it the top choice for overlanders, hunters, rescue teams, and anyone who refuses to compromise on capability or safety.
The Advanced Offroad Trailer ATV X3 sets a new benchmark in off-road trailer engineering, combining military-grade durability with high-performance design features rarely seen in civilian trailers. At just 350 lbs dry weight, it’s astonishingly lightweight, yet at the same time, built from 14g steel — a material five times stronger than standard structural steel. As a result, the ATV trailer is not only easy to maneuver by hand but also incredibly resilient in extreme off-road environments. Its fully articulating off-road hitch ensures unmatched safety and control, even in rollover scenarios, while the 9 inches of suspension travel and air-adjustable swing-arm suspension absorb punishing terrain with smooth, stable performance. No matter the load, whether you’re hauling 200 lbs or the full 1500 lb payload, the ride remains balanced, thanks to the trailer’s fully adjustable air spring system.
Off-Road Hitch
The AOT comes standard with a fully articulating off-road hitch. It fits a standard 2” ball, installs easily, and locks securely. The hitch allows the trailer to roll completely over without affecting the tow vehicle. As a result, the operator stays safe. The hitch also enables full vertical movement. A pintle hitch is available as an option.
Air Suspension
AOT trailers use fully adjustable air suspension. This lets you set the spring rate for loads between 200 and 1500 lbs. In addition, air suspension provides a more progressive spring rate than standard steel springs. Therefore, off-road performance improves, especially on off-balance loads or severe off-camber terrain.
Suspension Travel and Clearance
– 9 inches of suspension travel — Provides excellent performance in varied environments.
– Up to 22 inches of ground clearance — Matches the clearance of most ATVs. You may need a 1-inch drop hitch or greater to level the trailer.
Durable Finishes
– Fully powder-coated gloss military tan finish
– Other colors available, including actual Military Tan or custom options
High-Performance Features
– Anti-sway bar — Improves cornering and off-camber handling with polyurethane bushings.
– Adjustable hitch height — Fits various tow vehicle heights.
– Removable draw bar — Makes storage and shipping easier.
– LED taillights — Include a flat 4 plug, brake, running, and turn signal functionality. An adapter is available for three-wire vehicles.
Strong, Lightweight Build
The AOT features a fully welded frame with just nine grade 8 fasteners. This ensures maximum durability during aggressive off-road use. Despite its strength, the trailer weighs only 375 lbs. You can move it by hand.
Suspension and Axles
– 3500 lb axles per side — Designed for high load and off-road use.
– Swing arm suspension — Redirects terrain forces for a smoother ride.
– Polyurethane bushings — Absorb terrain energy, reduce fatigue, and ensure quiet operation.
Integrated Systems
– All wiring and air hoses are integrated into the frame for protection.
– Wires are rubber-coated to resist wear from vibration.
Practical Features
– Over 100 tie-down points to secure gear.
– Load- and highway-rated wheels and tires.
– VIN-coded for on-road use. Accessories are available to help meet local requirements.
